LED Searchlight
Honeywell Aerospace Technologies is a worldwide leader in the design, supply and support of exterior aircraft lighting systems. We have the experience and capability to design and deliver exterior LED lighting that meets real-world requirements through moisture protection, thermal management, power quality, optical design and control. Honeywell’s family of LED searchlights offers solutions for military and commercial helicopters worldwide.
A Standard In Aircraft Lighting You Can Trust
All Honeywell LED products undergo rigorous testing to ensure they meet advertised performance. Based on proven experience meeting performance, quality, reliability and on-time delivery commitments, Honeywell optimizes our LED applications in the areas of optical design and control, power management, thermal management, and environmental protection.
Product Benefits
- Improved pilot visibility at reduced lifecycle cost:
- Photometric Life of 25,000 Hrs. – 80x over Halogen
- Increased IR performance: 10x standard dual mode
- Reduced power: 400W to 60W Visible 200W to 40W IR
- LED output and color improves pilot visual acuity:
- 175,000 cd Visible / 100 NRI IR
- Dimmable
- 11° x 11° beam width
- Uniform light pattern in visible and infrared
- Weight neutral or decrease (variant dependent)
- Proven mechanical actuators
Product family part numbers and platforms
| LED Full Assembly P/N | LED Retrofit Kit P/N | Product Description | Corresponding Legacy Version | Platform(s) |
|---|---|---|---|---|
| 45-0202-201 | MK45-0202-001A | Single Mode Visible | 45-0202-1 | H-60 |
| 45-0241-201 | MK45-0241-001A | Single Mode Infrared | 45-0241-1 | H-47, H-60 |
| 45-0241-205 | N/A | Single Mode Infrared | 45-0241-5 | H-60 |
| 45-0241-207 | N/A | Single Mode Infrared | 45-0241-7 | H-60 |
| 45-0241-211 | MK45-0202-001A | Single Mode Infrared | 45-0241-11 | H-60 |
| 45-0253-213 | MK45-0253-016A | Dual Mode | 45-0253-13 | A129, Bk-117, BO-115, EC-135, H-1, H-53 |
| 45-0253-219 | MK45-0253-016B | Dual Mode | 45-0253-19 | A129, Bk-117, BO-115, EC-135, H-1, H-53 |
| 45-0253-223 | MK45-0253-016C | Dual Mode | 45-0253-23 | A129, Bk-117, BO-115, EC-135, H-1, H-53 |
| 45-0253-227 | MK45-0253-016D | Dual Mode | 45-0253-27 | A129, Bk-117, BO-115, EC-135, H-1, H-53 |
| 45-0253-235 | N/A | Dual Mode | 45-0253-35 | MK-41 |
| 45-0339-205 | MK45-0339-002A | Single Mode Visible | 45-0339-5 | A109, H-3 |
| 45-0339-207 | MK45-0339-002B | Single Mode Visible | 45-0241-7 | A109, H-3 |
| 45-0339-209 | MK45-0339-002C | Single Mode Visible | 45-0339-9 | A109, H-3 |
| 45-0339-211 | MK45-0339-002D | Single Mode Visible | 45-0339-11 | A109, H-3 |
| 45-0339-213 | MK45-0339-002E | Single Mode Visible | 45-0339-13 | A109, H-3 |
| 45-0339-215 | MK45-0339-002F | Single Mode Visible | 45-0339-15 | A109, H-3 |
| 45-0339-301 | MK45-0339-002G | Single Mode Visible | 45-0339-101 | A109, H-3 |
| 45-0339-304 | MK45-0339-002H | Single Mode Visible | 45-0339-104 | A109, H-3 |
| 45-0339-305 | MK45-0339-002J | Single Mode Visible | 45-0339-105 | A109, H-3 |
| 45-0353-201 | MK45-0353-002A | Dual Mode | 45-0353-1 | B206, BK-117, BO-115, EC-135, H-1, H-3, H-47, H-53, H-60 |
| 45-0353-203 | MK45-0353-002B | Dual Mode | 45-0353-3 | B206, BK-117, BO-115, EC-135, H-1, H-3, H-47, H-53, H-60 |
| 45-0434-4-2 | MK45-0434-001A | Dual Mode, Dimmable USL | 45-0434-2-2 | H-47, H-60 |
| 45-0434-5-2 | MK45-0434-001B | Dual Mode, Non-Dimmable USL | 45-0434-3-2 | H-47, H-60 |
| 45-0441-5-2 | MK45-0441-001A | Dual Mode, Non-Dimmable USL | 45-0441-2-2 | H-60 |
| 45-0441-6-2 | MK45-0441-001B | Dual Mode, Non-Dimmable USL | 45-0441-3-2 | H-92 |
| 45-0441-7-2 | MK45-0441-001C | Dual Mode, Non-Dimmable USL | 45-0441-4-2 | MH-60S, MH-60R |
| 72450448-4-2 | MK72450448-001A | Dual Mode, Dimmable USL | 72450448-3-2 | CH-53K |
